Emerson ASCO Fuel Oil Valve, 266-S Series
Images are representations only.

ASCO 266-S Series Fuel Oil Valves

Brand: ASCO

266SA.png 266SB.png Series266.png Emerson ASCO Fuel Oil Valve, 266-S Series Emerson ASCO Fuel Oil Valve, 266-S Series
The ASCO 266-S Series is a line of solenoid valves designed specifically for the on-off control of fuel oil in commercial and industrial burners. The valves are suitable for light and heavy fuel oils.
Features
  • General-purpose brass enclosure for a variety of applications.
  • 2-way normally closed or normally open operation.
  • Zero-differential lever actuation.

    • Specifications

    Brand

    Body Material

    • Brass

    Flow

    • From 0.1 Cv to 0.5 Cv, from 0.5 Cv to 1.0 Cv, from 1.0 Cv to 2.0 Cv, from 2.0 Cv to 6.0 Cv

    Function

    • 2-Way - 2/2 Normally Closed, 2-Way - 2/2 Normally Open

    Max. Differential, Max. Operating Pressure

    • Vacuum to 10.3 bar, Vacuum to 150 psig, 10.3 to 34.5 bar, 150 to 500 psig, more than 34.5 bar, more than 500 psig

    Media

    • Fuel Oil

    Operating Environment

    • Indoor, Outdoor

    Pipe / Port Size

    • 1/2, 3/8, 3/4

    Port Type

    • Female NPT

    Standards & Regulations

    • CSA, FM, Typical 1, Typical 2, Typical 3, Typical 3R, UL

    Valve Actuation

    • Lever, Solenoid, Solenoid - Direct-Acting

    Voltage

    • 24 AC, 110 AC, 115 AC, 120 AC, 208 AC, 220 AC, 230 AC, 440 AC, 480 AC - 50, 60
