Emerson ASCO Dual-flow valve, 292 Series
Images are representations only.

ASCO 292 Series Valves

Brand: ASCO

The ASCO 292 Series is a line of compact aluminum flanged bodied dual-flow valves designed specifically for petrol vending applications. The valves offers three flow positions: full flow, low flow, and shut off.
Features
  • Valves can be mounted in any position.
  • Explosion proof operators, intended for use in potentially explosive areas, according to Directive ATEX 94/9/EC.
  • Easy electrical installation supplied with a pre-moulded 2 M electrical cable.
  • Satisfies all relevant EC directives.

    • Specifications

    Brand

    Body Material

    • Aluminum

    Function

    • 2-Way - 2/2 Normally Closed

    Max. Differential, Max. Operating Pressure

    • Vacuum to 10.3 bar, Vacuum to 150 psig

    Operating Environment

    • Hazardous

    Pipe / Port Size

    • 3/4, 1

    Port Type

    • G ISO228 / 1-G BSPP

    Valve Actuation

    • Solenoid

    Voltage

    • 24 DC, 48 DC, 24 AC, 115 AC, 230 AC/50/60, 50
