TY520 Digital Multimeter
Brand: YokogawaThe TY series, simply performing special operations via front panel allows for quick and reliable adjustment. In addition, the series allows for onetouch adjustment of AC voltage- and AC current-to-frequency characteristics.
The user calibration function leads to improved operation efficiency and cost reduction.
Features- High Precision
- Basic accuracy 0.09%
- True RMS measurement
- Ensured Field Site Safety
- Conforms to safety standards EN61010-1, 1000V CAT III, 600V CAT IV
- Safety shutters for preventing erroneous insertion of test leads into current measurement terminals
- New Functions for Yokogawa Middle Class DMMs
- Current direct reading function provided by current clamp sensor (optional)
- Low-pass Filter (LPF)
- Logging-mode memory for 1600 data
- USB communication, application software (Optional DMM communication package) TY530 only
- Closed Case Calibration
- 3-year Warranty
Specifications
Brand
Accuracy
- ± (0.09% of Reading + 2-Digits) - DC Voltage Measurement
- ± (0.15% of Reading + 2-Digits) - DC Voltage Measurement
- ± (0.2% of Reading + 2-Digits) - Frequency Measurement
- ± (0.5% of Reading + 5-Digits) - DC Current Measurement
- ± (1% of Reading + 5-Digits) - AC Voltage Measurement, Diode Test
- ± (1.5% of Reading + 5-Digits) - AC Current Measurement
- ± (2% of Reading + 2-Digits) - Resistance
Approvals & Certifications
- CE
- CSA
- EMC: EN 61326-1 Class B, EN 55011 Class B Group 1, EN 61326-2-1
- UL 61010-1, CAN/CSA-C22.2 No. 61010-1, UL 61010-031, CAN/CSA-C22.2 No. 61010-031, CULus
Approvals & Certifications
- EN 61010-031
Battery Life
- Approximately 300 Hours (For Continuous DC Voltage Measurement with Alkaline Cells)
Current
- < 1.2 mA - Maximum
- 600 µA - 10 A - DC Current, AC Current Measurement
Display
- 3.5-Digit LCD 7-Segment
- Backlit
- Bar Graph: 31 Segment
- Digital Display: [6,000] Counts
Function
- Auto Hold
- Auto Power Off
- Communication Function
- Data Hold
- Filter
- Overvoltage Input Warning
- Relative Value Computation
Humidity
- 70% Relative Humidity, Non-Condensing - Storage & Operating Conditions
- 80% Relative Humidity, Non-Condensing - Operating Conditions
Indication
- Low Battery Indicator
- Overrange Indicator: "OL"
- Polarity Indicator
Input
- 0.2 to 600 Vrms to Frequency Measurement
- 1,000 Vdc - Maximum
- 1,000 Vrms - Input Protection Voltage for Resistance, Temperature Measurement, Diode Test, Continuity Check, Capacitance
- 1,000 Vrms AC - Maximum
- 10 A Fuse Protected - Maximum
- 440 mA Fuse Protected - Maximum
Input Impedance
- 10 MegaOhms, < 200 PF & < 50 PF - AC Voltage Measurement
- 11 MegaOhms, < 50 PF - AC Voltage Measurement
Measuring Range
- Bar Graph Display: 25 times/second
- Capacitance: Maximum
- DC Voltage, Diode Test: 5 times/second
- Frequency: 1 Time/second
- Resistance: 2.5 times/second
- Temperature: 0.7 times/second
Operating Temperature
- -10° to 55° C (14° to 131° F)
- 40° to 55° C (104° to 131° F)
Power Supply
- 4 AA Alkaline Batteries (R6) Dry Cells
Resistance
- 10 MegaOhms - Input Resistance
- 11 MegaOhms - Input Resistance
Resolution
- 0.001 V - Diode Test
- 0.1 A - AC Current, DC Current Measurement
- 0.1 Hz - Frequency Measurement
- 0.1 ohms - Resistance Measurement, Continuity Check
- 0.1° C - Temperature Measurement
- 1 µF - Capacitance
- 1 V - AC Voltage, DC Voltage Measurement
Response Time
- 1 second or less - DC Voltage, DC Current Measurement
- 10 seconds or less for 6 to 60 MegaOhms Resistance Measurement
- 2 seconds or less for 600 ohms to 600 KiloOhms Resistance Measurement, AC Voltage Measurement
- 3 seconds or less - AC Current Measurement
Sensor, Probe Type
- K Thermocouple
Storage Temperature
- -30° to 70° C (-22° to 158° F)
Supply Voltage
- < 1.3 V - Open Circuit Voltage for Resistance Measurement
- < 3.5 V - Open Circuit Voltage for Resistance Measurement, Diode Test, Continuity Check
- 6.88 kV for 5 seconds (Between Input Terminals & Casing)
- 600 mV-1,000 V - DC Voltage, AC Voltage Measurement
Voltage Drop
- < 0.1 V/A - DC Current, AC Current Measurement
- < 0.12 mV/µA - DC Current, AC Current Measurement
- < 3.3 mV/mA - DC Current, AC Current Measurement
