FP1P Pulse Repeater
Brand: Yokogawa
The FP1P is a compact, front terminal connection type pulse repeater that converts pulses from voltage-free contacts, open collector contacts, voltage, and current into isolated transistor switch pulses.
Features- With built-in 12 V or 24 V power supply for transmitter inputs
- Internal filter can be set to eliminate chattering. (In cases where the input frequency range is up to 100 Hz, the pulse width is 3 ms or more)
Specifications
Brand
Consumption
- 60 mA at 24 Vdc
Electrical Connectors
- M4 Screw Terminal
Electrical Rating
- 15 mA - Maximum
- 30 mA - Maximum
Enclosure, Body Material
- ABS Resin
Frequency
- 0 to 10,000 Hz - Input Frequency in Case the Input is Voltage Pulse & the Swing is 5 V or more
- 0 to 6,000 Hz - Input, Output Frequency
Humidity
- 5 to 90% Relative Humidity Non-Condensing - Operating Humidity Range
Input
- Relay Contact
- Transistor On/Off Contact
Input Signal
- 2-Wire - Voltage-Free Contact Pulse, Voltage Pulse, or Current Pulse
- 3-Wire - Voltage Pulse or Current Pulse
Insulation Resistance
- 100 MegaOhms or more at 500 Vdc between Input & Output, Output & Power Supply & Input & Power Supply
Mounting
- DIN Rail Mounting
- Rack-Mounted
- Wall Mounted
Operating Temperature
- 0° to 50° C (32° to 122° F)
Output Format
- Transistor Output (Open Collector)
Power Supply
- 12 Vdc ± 10%
- 24 Vdc ± 10% (Percentage Ripple is 5% peak-to-peak or less)
- 30 mA or less
Power Supply Effect
- ± 0.1% of Span or less for the Fluctuations within the Operating Range of Power Supply Voltage Specification
Pulse Range
- 60 µs - Minimum Input Pulse Width ON, OFF
Resistance
- 1 KiloOhm - Internal Load Resistance (For Current Pulse)
- 100 KiloOhms or more - Contact Resistance Open
- 15 KiloOhms or more for Contact or Voltage Pulse - Input Resistance
- 200 ohms - Internal Load Resistance (For Current Pulse), or less for Contact Resistance Close
- 510 ohms - Internal Load Resistance (For Current Pulse)
Supply Voltage
- -1 to 8 Vdc - Low Level
- 1,500 Vac/minute between Input & (Output & Power Supply) - withstand Voltage
- 3-24 Vdc - High Level
- 500 Vac/minute between Output & Power Supply - withstand Voltage
