WU20 Electrode Cable
Brand: YokogawaThe program of Yokogawa includes a range of high quality, low-noise cables for accurate transmission of low voltage signals even in areas where interference is present. They have a shield with an internal anti-noise sheath and can be connected to all pH and ORP (Redox) electrodes fitted with an O-connector.
At the electrode end the cables are provided with a socket having spring gilded contacts for secure connection to the sensor. The combination electrode plug and cable socket is watertight and temperature resistant up to 125° C. It meets the requirements of IP65.
Features- Internal anti-noise sheath for accurate measurement
- Gold plated spring O-connectors parts, for good electrical contact under the most severe conditions
- Coaxial plug and socket with watertight sealing that meets the requirements of IP65
- Cables for industrial applications and for laboratory use are available
Specifications
Brand
Applications
- Industrial Applications
- Laboratories
Cable Length
- 3.2 to 82 feet (1 to 25 meters)
Electrical Connectors
- 2 mm Contact Pins - Wire Connections
Electrical Contacts
- Gold-Plated Spring O-connectors Parts - Good Electrical Contact
Environmental Protection
- Intrinsically Safe
- IP65
- Watertight
Length
- 50 mm - Bending Radius
Temperature Range
- Maximum
